CABINET BODY
• Heavy-gauge formed and welded galvanized steel cabinet body construction provides strength and durability.
• Full height 18 gauge rear access panel are removable to provides full access to service chase
• Shelf is height adjustable by heavy-duty zinc-plated shelf support clips which are adjustable in Vz' increments
• Flush comer construction for smooth seamless cabinet face
• Base cabinet are available in many styles of cupboard units, drawer units and drawer & cupboard units.They are available in standard length 462mm, 512mm, 600mm, 750mm, 900mm, 1000mm.Standard heights are 600mm, and standard depth is 500mm.
• 18 Gauge Uprights with holes for shelf clip attachment
• Hole for top attachment
• 11 Gauge gusset to fix the hex head leveling screw for easy adjustment
• 20 Gauge adjustable shelf, shelves over 36" long have a hat channel reinforcement
• 16 Gauge Intermediate front horizontal rail
• 18 Gauge Toe base & bottom
• Access for leveling adjustment
• 5-Knuckle institutional type stainless steel hinge.
• Rubber door dampers.
• Variety of door and drawer pulls available.

STEEL FINISH

Environmentally friendly, electronically applied powder coat finish

Laboratory grade formulation meets all SEFA 8 chemical requirements.

1.Metal preparation prior to application of finish, consisting of multiple-
step process:
• Cleaner/phosphate spray
• Water rinse
• Passivating sealant spray

2.Parts to be dried at elevated temperatures and cooled prior to application of finish; finish to be applied in powder form, electrostatically charged, to all interior and exterior channel surfaces to an average thickness of 1.5 mils; immediately after application, coated surfaces to be baked in high temperature, continuous ovens to provide uniform curing for abrasion and chemical resistance as required for service in laboratory environment.
